Upgraded W10830162 Refrigerator Door Gasket Replacement Compatible with Whirlpool Kenmore KitchenAid Refrigerator, 39.7"x 16.93" Freezer Door Gasket Refrigerator Door Seal Part 12723206AP, W10179332

Brand: Luckman

Color: Grey

Features:

• [Specification of Fridge door seal]the W10830162 Whirlpool refrigerator seals dimension is 39.7"x 16.93" ,Color: gray. Measurement Method: Remove the refrigerator seal, measure the length and width between the outer diameter of the slots on the refrigerator door, and then measure the width of the slots to get the exact size of the seal. NOTE: On some model refrigerators this gasket is used only for the right door, and the left door uses a smaller gasket that requires a different part number. On some model refrigerators this gasket is used for the left and right doors. Please verify you are ordering the correct gasket before placing your order.
• [Upgraded and Reliable Material] Whirlpool W10830162 Refrigerator Door Gasket is made of High quality EPDM rubber with precision welding process,1600 degrees fahrenheit high temperature welding. Featuring Cold resistence, high elasticity and flexibility, can quickly return to its original state after deformation.
• [Superior Sealing, Fit Perfect] Thicken magnetic strips, resistant to bending, strong suction for effective sealing and functions the same as original OEM-branded parts, but quality seal better than OEM. Perfect insulates the outside air and creates a low-temperature environment to keep your food fresh. You no longer need to worry about food being oxidized or contaminated, W10830162 door gaskets will guard the deliciousness for you.
• [Replace Part Numbers]Part W10830162 refrigerator door sealer replaces these parts: 12723206AP, W10179332, W10179332N, W10199876, W10443225, W10571956. Durability upgraded W10830162 refrigerator gasket replacement can perfect solve following problems: ➊Door gasket broken torn, worn ➋Dirty gasket ➌Leaking / poor seal ➍Condensation builds up/ frost / ice build up inside
• [Wide Compatibility] W10830162 fridge door gasket compatible with Whirl-pool, Ken-more, Kitchen-Aid, May-tag, Jenn-Air, Dacor. Including WRF535SWHZ, WRF535SMBM, KRFC300ESS, KRFF305ESS and WRF535SWHV, IX6HHEXDSM00, IX6HHEXDSM01, IX7HHEXDSM00, KBFS20EVMS13, KBFS22EWMS9, KRFC300ESS01, KRFF305ESS00, WRF535SMBM00...more compatibility, please check our product page. Before purchasing, check your device's model number to ensure compatibility.
• [Installation Steps] Step 1. The first thing you need to do is unfold it and lay it flat with the surface that will attach to the flat surface of the door down flat on the floor for a day or two, so you can get any kinks or folds out of it before you install it. Step 2. If any part of it isn't laying flat on the floor, take some painters tape or packing tape and tape it down flat. Step 3. If that still doesn't work, use a hair dryer and massage the kinks out with your fingers or get some hot water and dip the affected portion in the water and massage the kinks out. Step 4. Then, grab your old gasket at the top and begin to pull it out working your way around the door.
• [Installation Steps] Step 5. To install the new seal, find the short edge that looks like there is a tab sticking out and place that in the top corner of the door where you are replacing it. Step 6. The flat part of the seal should be on the outside because this is where it will seal to the refrigerator opening surface. Step 7. Starting at the top outer conner work your way down, firmly pushing the seal into the grooves of the refrigerator door. Step 8. Once you reach the bottom, go back to the top edge and push the seal in across the top horizontally, then work your way down the other long edge on the inside and finally, push it in across the bottom.
• [Compatibility] W10830162 Refrigerator Door Gasket Seal is compatible with KitchenAid models: KRFF305EBL00 KRFF305EBS00 KRFF305EWH00 KRFF305ESS00 KRFF302ESS02 KRFF305ESS02 KRFC300ESS03 KRFF305EWH02 KRFF305ESS03 KRFC300EWH03 KRFF302EWH04 KBFS22EWMS9 KBFS22EWWH1 KBFS25ECBL00 KBFS25ECMS00 KBFS25ECWH00 KBFS25EVBL0 KBFS25EVWH00 KBFS25EVWH1 KBFS25EWBL0 KBFS25EWBL1 KBFS25EWBL2 KBFS25EWBL3 KBFS25EWBL4 KRFC300ESS01 KRFC300EWH00 KRFF302EBL00 KRFF302EBL01 KRFF302ESS00 KRFF302ESS01 KRFF302EWH00 KRFF302EWH01...more compatibility, please check our product page. Before purchasing, check your device's model number to ensure compatibility.
• [Compatibility] W10830162 Refrigerator Door Gasket is compatible with Whirlpool models: GX5FHTXVY02 GX5FHTXVY03 GX5FHTXVY04 GX5FHTXVY05 GX5FHTXVY06 GX5FHTXVY07 GX5FHTXVY08 GX5FHTXVY09 GX5SHDXVA00 GX5SHTXVY01 GX5SHTXVY02 JFC2089WEP4 KBFS25EVMS3 KRFC300ESS01 MFC2062DEM01 WRF532SMBB00 WRF532SMBB01 WRF532SMBM00 WRF535SMBB00 WRF535SMBM00 WRF535SWBB00 WRF535SWBM00 WRF535SWBW00 WRF540CWBB00 WRF540CWBB01 WRF540CWBM00 WRF540CWBM01 WRF532SMHV00 WRF532SMHW00...more compatibility, please check our product page. Before purchasing, check your device's model number to ensure compatibility.

model number: W10830162

Part Number: W10830162,12723206AP,W10179332,W10199876

Package Dimensions: 18.0 x 18.0 x 2.5 inches
